UPFITTER SWITCHES

Overview

You just got your new horn kit up and running and you want to set it up on the up-fitter switches. No ideas where to start? Don't worry, we've got you covered.


The Switches

Chances are that if you are reading this article, you are already familiar with these switches and the wires that connect to them. If not, check out the quick guide below to find these switches on your vehicle.

If you've already figured out where the leads are, go ahead and skip to the bottom of this article.


2005-2007 Ford Super Duty Upfitter Switches:

The Ford Upfitter Switches are optional instrument panel mount switches (Option Code 66S) that control passenger-side mounted relays. These relays power four blunt cut wires that can be found beneath the steering column and behind the passenger compartment fuse panel also called the Central Junction Box (CJB). The wires are part of the harness connected to the “K” connector (C270K) on the back of the CJB. The four wires are as follows:

Switches Circuit Color Fuse
Aux 1 1936 Orange/Light Green 30 Amp
Aux 2 1933 Orange 30 Amp
Aux 3 1934 Orange/Yellow 10 Amp
Aux 4 1935 Orange/Light Blue 10 Amp

The Upfitter Switches are operational when the ignition key is in the run position. The Upfitter Switches cannot be utilized in any other operational mode. The power to the switches is relay controlled and was designed to operate in the “run” mode to reduce the possibility of draining the battery(ies).


2008-2010 Ford Super Duty Upfitter Switches:

The Ford Upfitter Switches are optional instrument panel mount switches (Option Code 66S) that control passenger side mounted relays. These relays power four blunt cut wires that are taped on a harness near the relay pack that can be found beneath the instrument panel and to the left of the steering column. The four blunt cut wires are as follows:

Switches Circuit Color Fuse
Aux 1 CAC05 Yellow 30 Amp
Aux 2 CAC06 Green/Brown 30 Amp
Aux 3 CAC07 Violet/Green 10 Amp
Aux 4 CAC08 Brown 15 Amp

How to locate the leads for these switches:

1. Remove the trim cover below the steering column.

2. Locate the relay pack beneath the instrument panel and to the left of the steering column.

3. Locate the four blunt cut wires with shrink wrap on the harness near the relay pack.

The Upfitter Switches are operational when the ignition key is in the “RUN” position only. The power to the switches is relay controlled and was designed to operate in the “RUN” mode to reduce the possibility of draining the battery(ies).


2011 And Later F-Series Super Duty Upfitter Switches:

The Ford Upfitter Switches are optional instrument panel mount switches (Option Code 66S) that control passenger side mounted relays. These relays power four blunt cut wires that are taped on a harness near the relay pack that can be found beneath the instrument panel and to the left of the steering column. The four blunt cut wires are as follows:

Switches Circuit Color Fuse # Rating
Aux 1 CAC05 Yellow F94 25A
Aux 2 CAC06 Green/Brown F95 25A
Aux 3 CAC07 Violet/Green F9 10A
Aux 4 CAC08 Brown F2 15A

To find the wires:

1. Remove the trim cover below the steering column.

2. Locate the relay pack beneath the instrument panel and to the left of the steering column.

3. Locate the four blunt cut wires with shrink wrap on the harness near the relay pack.

Honking Your Horns with the Upfitter Switches

Surprisingly, this is the easiest part of the process. Once you have decided on an up fitter switch to use, you may route the output lead from the desired switch out to one wire on our solenoid valve. The opposite lead from our valve can be run to the frame of the vehicle as a ground point. This will complete the circuit, and your horns will honk once the switch is flipped on.

If you are looking to use the up-fitter switch to turn the train horns on and off at the steering wheel, please see our article here.
